6W Constant Current Led Driver

# BLD-6-XX
Model BLD-6-350 BLD-6-500 BLD-6-700 BLD-6-1050
Output Current 350ma 500ma 700ma 1050ma
Tolerance 5%
Output Voltage 3-20 Vdc 3-12Vdc 3-9Vdc 3-5Vdc
Power 6W
Efficiency 86% 85% 84% 82%
Input Voltage 170-260 Vac
Frequency 50-60 Hz
Submit an Inquiry
Item can be shipped to all over the world.
Inquiry Form
Your Idenfity

*Your Name:

Company Name:

Address:

Telephone or Mobile/Call Phones:

Email:

Your Product Need

Additional Comments:

Model Description is 6 Watt Constant Current LED Driver. These driver have various models such as 350, 500, 700 and 1050 ma. 6 Watt Constant Current LED Driver regulates the LED’s operating current and make the LED system work properly. 6 Watt Constant Current LED Drivers have IP67 and IP20 outer casing options.

Product Features Applications
  • High efficiency (>%85)
  • Wide range of input voltage(170-260Vac)
  • Short circuit protection
  • Over Load Protection
  • Thermal closing with hysteresis
  • Minimum standby power consumption (<0,2W)
  • Long life capacitor



  • Led indoor lighting
  • Led office lighting
  • Led architectural lighting
  • Led panel lighting



Technical Specifications
Working Temperature-Humidity -10° … +70°,  20-90% RH
Durabilitiy Temperature-Humidity -20° … +80°, 10-95% RH
Dimensions(L*W*H) 48*24*20 mm
Weight 0,065 Kg
Short circuit protection Automatic restart
Protection Class IP 67
Technical Drawing
